LeCroy WaveRunner 64Xi-A-N Oscilloscope Upgrade Attempt

Video

  By Scott • 2023-11-03 ,

I got this LeCroy WaveRunner 64Xi-A-N Oscilloscope from eBay because I needed a faster scope than my best 200Mhz Siglent model.

On eBay it looked super clean and in good cosmetic shape, and was shown and claimed to be working. When I received it, it would kinda start up, but the display was blank and overall it was unresponsive. When I went to make this video showing the investigation, it powered right up! Strange.

So I figured I’d just be replacing the RTC battery and upgrading the HDD to an SSD. Turns out it already had an SSD and a new battery. The problem was that it would reboot every time the USB ports were even slightly jostled.

After getting the motherboard out (which is standard-ish mini ITX style), it turns out that the PCB is really badly warped. That’s probably leading to cracked and/or damaged traces, possibly in internal layers. I’d wager that’s the cause of the reboots.

I posted this video more for posterity and in case anyone wanted to see an albeit slow teardown. Apologies for the rambly nature, but this really didn’t go according to plan.

No comments

Exploring the Sonic Foundry Mediasite Recorder from 2008ish

Video

  By Scott • 2021-12-13 ,

I open up this device from the past to see what it was all about, and how useful the chassis might be for modern purposes.

This is the edited version of a live stream I did almost 2 years ago (just got around to it), so if you want to see all the faffing that went into it, a recording of double the length is available here: https://youtu.be/4_xDG0fsMU4

No comments

One-Netbook’s OneGX1 Pro – Didn’t Buy it for Gaming (with Teardown)

  By Scott • 2021-09-11 , ,
OneGX1 Pro - YouTube Cover Image 01 - v1 - P1010254

I’ll admit I was charmed by the full-sized specs of this diminutive laptop (or netbook, as you will), and I have a thing for tiny laptops in general. So I couldn’t resist it when Banggood offered it up to me in a full-on tracking cookie assault of marketing. (That being said, I purchased it from Amazon to avoid paying duties.) It’s a solidly built little machine, and a solid performer save for one thing: It’s not what I would consider to be a gaming computer. Though it is indeed sold as one, what with it’s somewhat-included side controllers and advertising to that effect. Sure, it can play some games just fine, but without some kind of even halfway-decent (even mobile-optimized) … Continue reading

No comments

Disconnecting the Battery in a Teradek VidiU Pro (Live)

  By Scott • 2020-02-27 ,
Disconnecting the Battery in a Teradek VidiU Pro (Live) - YouTube Cover Image

I’ve been trying out different streaming tools and software lately, and ultimately I prefer the dedicated hardware approach. The Teradek VidiU Pro has been discontinued by the manufacturer, and can be had for some pretty good deals on eBay. The VidiU Pro can be used to live stream events from remote and outdoor locations using either WiFi or a connected USB cell modem. It’s also got an ethernet port (and of course a power input) for use in fixed locations. Such as my basement. The problem for me is that the VidiU has a built in battery for portable use, meaning that when I shut off my equipment at the main PDU, the VidiU stays on until the battery runs … Continue reading

No comments

Amazon Echo Look – Teardown

  By Scott • 2017-11-04 ,
Amazon Look - Teardown - All Parts - Top - YouTube Cover - Attempt 01 - 1080p

The Echo Look I’m working on a full review-type-thing of the Look, but who really cares about that? I’m sure people will want to see the insides of it, though. The most interesting two things on it are an Intel RealSense SR300 module (minus its visible light camera), and what’s basically a full Intel PC motherboard. In fact, here are the main specs: Intel Atom x5-Z8350 (SR2KT) @ 1.44Ghz (1.91Ghz burst) 8GB Samsung eMMC Flash NAND Storage 8GB Elpida LPDDR3 RAM Broadcom 802.11ac + 802.11b/g/a/n + Bluetooth (Not sure of the version) The hardware is fantastically made and well put together, and overall is very clever considering they stuffed all of it into a diminutive cylinder! The Reassembly I did … Continue reading

No comments

Like Bees, the Yellow Jacket Power Strip (by Coleman Cable) is Terrible

Video

  By Scott • 2017-09-28 , ,

Another sh*tty power strip

Welp, they’ve done it again. Any by “they”, I mean people that make poor quality electrical devices. Specifically Yellow Jacket, which is a Woods brand, which is a Coleman Cable brand, which is probably somehow owned by either Warren Buffet or the Koch Brothers.

I got this for $16.22 during an Amazon lighting deal, and even though that’s not a terrible price, the poor quality construction and the basic lie about the materials is what really angers me.

Join me as I disassemble and then curse at this poor excuse for a power strip, in my newest installment of first world problems.

No comments

TechnicalPro PS9U Fire Hazard? (Yes, IMO) + Completely Safe Cyberpower CPS-1220RMS

Video

  By Scott • 2017-06-11 ,

I was searching for an “affordable” power distribution unit for some video-related equipment in a rack. The Technical Pro PS9U looked very appealing with its multiple light-up switches on the front, because they made me all sentimental and wistful for the days of switched under-monitor PDUs.

It took a dark turn when I looked at the negative reviews on Amazon, wherein one person uploaded pictures of a melted-down unit. I still bought the PDU, not because I wanted to use it, but purely because I wanted to take it apart for YouTube.

And indeed the Amazon review turned out to be accurate. I would not feel comfortable using the Technical Pro PDU in my house. In my opinion as a random guy on the internet, it is a fire hazard, is poorly made, and shouldn’t even be on the market.

For my actual use, I also bought a Cyberpower CPS-1220RMS PDU. It’s a bit different than the Technical Pro in that it doesn’t have independently-switched outputs, offers surge protection, and is rated at 20A rather than 15A (though “rated” is a strong word in the case of the PS9U). That’s just on the surface, though. Inside, the Cyberpower shows every mark of quality and clearly supports its 20A rating.

In the video I open up the Cyberpower, just to show you what a quality PDU should look like. The comparison between the two products is day and night, even though I got the Cyberpower unit for a mere $15 more (on sale). It’s absolutely worth the higher price (even when not on sale).

The bottom line here is that when it comes to power distribution — be it rack-mounted or a typical power strip style — you should spend the extra money to get the higher-quality unit. Your fire insurance provider will thank you, as might your family (if it comes to that).

No comments

Etekcity “Outdoor” Collapsible “Camping” LED Lanterns of Doom

Video

  By Scott • 2016-10-06 , ,

Here are some collapsible LED “camping” lanterns from Etekcity. The reason I put “camping” in quotes is because there is no sign of waterproofing on these things.

I suppose if you’re camping in the desert they’d be fine.

Wait, no they wouldn’t be. Because one out of the four didn’t work, and the soldering was abysmal. If you want to see details, I do a tear down in the video.
